Cable reels KR 500
KR 500 is built for combined three-phase and single-phase connection. It suits machines, assembly work and sites where power needs to stay on one reel.
Types 501, 502, 503 and 504 have a 5x16 A plug, round 5x16 A socket, 2 PCE sockets with covers and a 3 KBF fuse. Reel diameter is 280 mm.
Versions and technical data
| 501 | H05 VV-F 5G2,5, 33 m, EAN 3830008293138 |
|---|---|
| 502 | H05 RR-F 5G2,5, 33 m, EAN 3830008293145 |
| 503 | H07 RN-F 5G2,5, 33 m, EAN 3830008293176 |
| 504 | H05 RR-F 5G2,5, 25 m, EAN 3830008293183 |
Instructions, safety and warranty
The cable reel manual shows the CE mark and conformity certificate SIQ C21-20121/03. Warranty coverage is 2 years from purchase when the reel is used as instructed, with the original invoice and without unauthorized modifications.
